Remote Control Commands
R&S
®
SMB100A
335Operating Manual 1407.0806.32 ─ 21
Example:
CORR:DEXC:MODE IMP
selects that ASCII files with frequency and level value pairs are
imported and transferred into user correction lists.
CORR:DEXC:AFIL:SEL '/var/user/ucor.csv'
selects that ASCII file ucor.csv is imported.
CORR:DEXC:SEL '/var/user/ucor_imp'
selects that the ASCII file ucor.csv is imported into user cor-
rection list ucor_imp.
Manual operation: See "Mode - User Correction" on page 161
[:SOURce<hw>]:CORRection:DEXChange:SELect
<Filename>
Selects the user correction list to be imported or exported.
The user correction files are stored with the fixed file extensions *.uco in a directory
of the user's choice. The directory applicable to the commands is defined with the com-
mand MMEMory:CDIR. A path can also be specified in command
SOUR:CORR:DEXC:SEL, in which case the files are stored or loaded in the specified
directory.
Parameters:
<Filename> string
Example:
CORR:DEXC:MODE IMP
selects that ASCII files with frequency and level value pairs are
imported and transferred into user correction lists.
CORR:DEXC:AFIL:SEL '/var/user/import_ucor.csv'
selects that ASCII file ucor.csv is imported.
CORR:DEXC:SEL '/var/user/import_ucor_imp'
selects that the ASCII file ucor.csv is imported into user cor-
rection list ucor_imp.
Manual operation: See "Destination / Source - User Correction" on page 162
[:SOURce<hw>]:CORRection:CSET[:SELect] <Filename>
Selects or creates a file for the user correction data.
If the file does not exist, the instrument automatically creates a new file with the name
you assigned. Note the predefined file extensions under Chapter 4.7.2.1, "Extensions
for User Files", on page 85.
To determine the file location (directory/path) you can either enter it with the command
directly, or use the command MMEMory:CDIR.
To activate level correction use the command [:SOURce<hw>]:CORRection[:
STATe].
Parameters:
<Filename> <table name>
SOURce Subsystem
