R&S SMB100A User Manual

Remote Control Commands
R&S
®
SMB100A
349Operating Manual 1407.0806.32 ─ 21
Example
The following example shows how to set an LF sweep.
1. Set the sweep range.
LFOutput:FREQuency:STARt 4 kHz
LFOutput:FREQuency:STOP 10 kHz
2. Select linear or logarithmic sweep spacing.
LFOutput:SWEep[:FREQuency]:SPACing LIN
3. Set the step width and dwell time.
LFOutput:SWEep[:FREQuency]:STEP[:LINear] 100 Hz
LFOutput:SWEep[:FREQuency]:DWELl 20 ms
4. Determine the sweep mode.
LFOutput:SWEep:MODE AUTO
5. Determine the trigger.
TRIGger0:SOURce SINGle
6. Activate the sweep.
LFOutput:FREQuency:MODE SWEep
7. Trigger the sweep (depending on the mode).
LFOutput:SWEep:EXECute
[:SOURce]:LFOutput<ch>:FREQuency.............................................................................349
[:SOURce<hw>]:LFOutput:FREQuency:MANual............................................................... 350
[:SOURce<hw>]:LFOutput:FREQuency:MODE................................................................. 350
[:SOURce<hw>]:LFOutput:FREQuency:STARt................................................................. 351
[:SOURce<hw>]:LFOutput:FREQuency:STOP.................................................................. 351
[:SOURce]:LFOutput[:STATe]..........................................................................................352
[:SOURce<hw>]:LFOutput:SWEep[:FREQuency]:DWELl................................................... 352
[:SOURce<hw>]:LFOutput:SWEep[:FREQuency]:EXECute................................................ 352
[:SOURce<hw>]:LFOutput:SWEep[:FREQuency]:MODE....................................................353
[:SOURce<hw>]:LFOutput:SWEep[:FREQuency]:POINts...................................................353
[:SOURce<hw>]:LFOutput:SWEep[:FREQuency]:RETRace............................................... 354
[:SOURce<hw>]:LFOutput:SWEep[:FREQuency]:RUNNing?..............................................355
[:SOURce<hw>]:LFOutput:SWEep[:FREQuency]:SHAPe...................................................355
[:SOURce<hw>]:LFOutput:SWEep[:FREQuency]:SPACing................................................ 355
[:SOURce<hw>]:LFOutput:SWEep[:FREQuency]:STEP[:LINear]........................................ 356
[:SOURce<hw>]:LFOutput:SWEep[:FREQuency]:STEP:LOGarithmic..................................357
[:SOURce]:LFOutput:SHAPe...........................................................................................357
[:SOURce]:LFOutput:SIMPedance...................................................................................358
[:SOURce]:LFOutput:VOLTage........................................................................................358
[:SOURce]:LFOutput<ch>:FREQuency <Frequency>
Sets the frequency of the LF signal in LFO:FREQ:MODE CW|FIXed mode.
SOURce Subsystem
