R&S SMB100A User Manual

Remote Control Commands
R&S
®
SMB100A
392Operating Manual 1407.0806.32 ─ 21
Parameters:
<Mode> SINGle | DOUBle | PTRain
SINGle
Enables single pulse generation.
DOUBle
Enables double pulse generation. The two pulses are generated
in one pulse period.
PTRain
A user-defined pulse train is generated The pulse train is defined
by value pairs of on and off times that can be entered in a pulse
train list.
*RST: SINGle
Example:
PULM:MODE DOUB
enables double pulse generation.
Options: R&S SMB-K23 (Pulse Generator), R&S SMB-K27 (Pulse Train)
Manual operation: See "Pulse Mode - Pulse Generator" on page 227
[:SOURce<hw>]:PULM:OUTPut:SYNC[:STATe] <Sync>
Configures the signal at the SIGNAL VALID connector.
Parameters:
<Sync> 0 | 1 | OFF | ON
ON
Generates a single pulse at the beginning of a pulse sequence,
e.g. to synchronize pulse modulation.
OFF
Returns the validity of the RF signal at the output:
1 (high), while the signal settles.
0 (low), when it is stable (valid).
*RST: OFF
Example:
PULM:OUTP:SYNC ON
uses the signal for synchronizing the pulse modulation.
Manual operation: See "Use SIGNAL VALID as Pulse Sync" on page 229
[:SOURce<hw>]:PULM:PERiod <Period>
Sets the period of the generated pulse. The period determines the repetition frequency
of the internal signal.
Parameters:
<Period> float
Range: 5 us | 20 ns to 100 s
Increment: 1us | 5 ns
*RST: 10 us
SOURce Subsystem
