R&S SMB100A User Manual

Remote Control Commands
R&S
®
SMB100A
416Operating Manual 1407.0806.32 ─ 21
Parameters:
<Deviation> integer
Range: 0 to 10 kHz
*RST: 2 kHz
Example:
SOUR:STER:RDS:DEV 2kHz
sets the RDS signal deviation according to standard.
Manual operation: See "RDS Deviation - Stereo Modulation" on page 217
[:SOURce]:STEReo:SOURce
<Source>
Selects the source for the audio signal.
Parameters:
<Source> OFF | LREXt | SPEXt | LFGen
OFF
No audio signal is provided, ARI and RDS signal can be gener-
ated separately.
LREX
The external audio signal is feed in via the analog L and R
inputs.
SPEX
The external audio signal is feed in via the digital S/P DIF inter-
face
LFG
The audio stereo signal is internally generated by the LF genera-
tor.
*RST:
LREXt
Example:
STER:SOUR LFG
The internal LF generator is used as modulation source for the
audio signal.
Options: R&S SMB-B5
Manual operation: See "Audio Source - Stereo Modulation" on page 213
[:SOURce]:STEReo:STATe <State>
Activates/deactivates stereo modulation.
Parameters:
<State> 0 | 1 | OFF | ON
*RST: OFF
Example:
STER:STAT ON
activates generation of stereo signal.
Options: R&S SMB-B5
Manual operation: See "State - Stereo Modulation " on page 213
SOURce Subsystem
