2.11 PUNCH UNITS (B702)
These instructions describe installation of the following punch units for the Finisher
SR4060/SR4070:
Punch Unit Type 3260 SC (B702)
Punch Unit Type 3260 2/4 EU (B702)
Punch Unit Type 3260 NA 3/2 (B702)
These punch units can be installed and used with the Finishers SR4060 and SR4070
only.
2.11.1 ACCESSORIES
Check the accessories and their quantities against the following list.
No. Description Q’ty
1. Punchout Waste Unit 1
2. Slide Drive Unit 1
3. Punch Waste Hopper 1
4. Screws (M3 x 6) 5
5. Side-to-Side Detection Unit 1
6. Punching Unit 1
