and
Adjustment
4.5.3 LASER SYNCHRONIZATION DETECTOR REPLACEMENT
1. Right side cover p.4-9
2. If the optional LCT is installed, disconnect it (
x 1).
3. Development unit fans [A] (
x 5, x 2)
4. Synchronization detector [B] (
x 1, x 1)
5. After replacement, set SP1002-001 to 007 (Side-to-Side Registration) to the defaults.
