Ricoh D131 - Tandem Right Tray Paper Sensor Replacement

Paper Feed
SM 4-101 D131/D132/D133
Replacement
and
Adjustment
4.11.4 TANDEM RIGHT TRAY PAPER SENSOR REPLACEMENT
1. Turn off the machine.
2. Remove the right tandem tray
p.4-97
3. Inner cover [A] (
x 2)
4. Side fences [B] (
x 1 each)
5. Bottom plate [C] (
x 4)
6. Connector [D] (
x 1)
7. Sensor [E] (
x 1)
