Ricoh D131 - Td Sensor

Development Unit
D131/D132/D133 4-60 SM
4.7.4 TD SENSOR
Remove:
 Development unit
p.4-34
1. TD sensor (
x 1) [A]
2. Before installing a new TD sensor, clean the TD sensor port [B].
3. After replacing the TD sensor, do these SPs:
 SP2801 TD Sensor Initial Setting
 SP2962 Auto Process Control (only if SP3901 – Auto Process Control – is on).
