Jam Detection
D131/D132/D133 6-8 SM
Main Unit and LCIT RT4010 (D613): Paper Jam Errors
No. Location Position Code
1 Initial Jam (Power On) A1
3 1st Paper Feed SN: Late A1
4 2nd Paper Feed SN: Late A1
5 3rd Paper Feed SN: Late A1
6 4th Paper Feed SN: Late (Japan Only) A1
7 LCT Feed SN: Late U
8 1st Vertical Transport SN: Late A1
9 2nd Vertical Transport SN: Late A1
10 3rd Vertical Transport SN: Late A1
11 4th Vertical Transport SN: Late (Japan Only) A1
12 Relay SN: Late B
13 Registration SN: Late B/C
14 Fusing Exit SN: Late D
15 Exit Unit Entrance SN: Late E
16 Paper Exit SN: Late E
19 Duplex Entrance SN: Late E
20 Duplex Transport SN 1: Late F
21 Duplex Transport SN 2: Late F
22 Duplex Transport SN 3: Late F
23 Duplex Exit SN: Late E
24 LCT Relay SN: Late U
34 By-pass Paper Feed SN: Late A2
To Next Page
