Jam Detection
SM 6-9 D131/D132/D133
Trouble-
shooting
No. Location Position Code
45 Sort Tray: Paper Exit SN: Late R
46 Sort Tray: Tray Lift Motor R
47 Sort Tray: Shift Tray Motor R
53 1st Paper Feed SN: Lag A1
54 2nd Paper Feed SN: Lag A1
55 3rd Paper Feed SN: Lag A1
56 4th Paper Feed SN: Lag (Japan Only) A1
57 LCT Feed SN: Lag U
58 1st Vertical Transport SN: Lag A1
59 2nd Vertical Transport SN: Lag A1
60 3rd Vertical Transport SN: Lag A1
61 4th Vertical Transport SN: Lag (Japan Only) A1
62 Relay SN: Lag B
63 Registration SN: Lag B/C
- - -
66 Paper Exit SN: Lag E
69 Duplex Entrance SN: Lag E
- - -
71 Duplex Transport SN 2: Lag F
72 Duplex Transport SN 3: Lag F
- - -
74 LCT Relay SN: Lag B
84 By-pass Paper Feed SN: Lag A2
