SC700: Peripherals
SM Appendix 2-67 D131/D132/D133
Appendix:
Service Call
Conditions
SC725-37 B
FM6 Pawl Motor Multi Folder (D615)
The FM6 pawl HP sensor did not detect the FM6 pawl in (or out
of) its home position. The 1st occurrence causes a jam, and the
2nd occurrence causes this SC code.
 FM6 pawl HP sensor dirty
 Sensor harness or connector loose, broken, defective
 FM6 pawl motor harness or connector loose, broken,
defective
 Sensor defective
 Motor or motor drive board defective
SC725-38 B
Fold Plate Motor Error Multi Folder (D615)
The fold plate HP sensor did not detect the fold plate in (or out of)
its home position within the prescribed time. The 1st occurrence
causes a jam, and the 2nd occurrence causes this SC code.
 Fold plate HP sensor dirty
 Sensor harness or connector loose, broken, defective
 Fold plate motor harness or connector loose, broken,
defective
 Sensor defective
 Motor or motor drive board defective
SC783-3 B
1st Fold Motor Error Multi Folder (D615)
The motor drive PCB detected an error at the motor.
 Motor harness or connector loose, broken, defective
 Motor or motor drive board defective
