Output Check Table
System Maintenance Section 3-41 D146/D147/D148/D149/D150
Input and Output
Check
5804
[OUTPUT Check]
Outputs PWM for electrify HVP (DC/AC:Y/M/C/K).
176 PP: Charge DC: Y ENG
[0 or 1 / 0 / 1/step]
177 PP: Charge DC: M ENG
178 PP: Charge DC: C ENG
179 PP: Charge DC: K ENG
180 PP: Charge AC: Y ENG
181 PP: Charge AC: M ENG
182 PP: Charge AC: C ENG
183 PP: Charge AC: K ENG
5804
[OUTPUT Check]
Outputs PWM for develop HVP.
184 PP: Development: Y ENG
[0 or 1 / 0 / 1/step]
185 PP: Development: M ENG
186 PP: Development: C ENG
187 PP: Development: K ENG
5804
[OUTPUT Check]
Outputs PWM for divide HVP.
194 PP: Separation ENG [0 or 1 / 0 / 1/step]
5804
[OUTPUT Check]
Outputs PWM for transfer HVP (image transfer: Y/M/C/K).
195 PP: ITB: Y ENG
[0 or 1 / 0 / 1/step]
196 PP: ITB: M ENG
197 PP: ITB: C ENG
198 PP: ITB: K ENG
