Kinetix 5500 Servo Drives
Performance Specifications with 200V-class Drive Operation and Frame 70 Linear Thrusters
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient temperature and rated line
voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Performance Specifications with 200V-class Drive Operation and Frame 100 Linear Thrusters
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient temperature and rated line
voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Linear Thruster
Cat. No.
Velocity, max
230V AC
m/s
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Force
N (lb)
System Peak
Stall Current
A 0-pk
System Peak
Stall Force
N (lb)
Rated Output
230V AC
kW
Kinetix 5500 Drives
(240V AC input)
LDAT-S072010-DDx
…
LDAT-S072070-DDx
3.5 6.0
364 (82)
22.0
1055 (237)
1.03 2198-H025-ERSx
LDAT-S072010-EDx
…
LDAT-S072070-EDx
1.7 3.0 11.0 0.47 2198-H015-ERSx
LDAT-S073010-DDx
…
LDAT-S073070-DDx
3.5 9.0
554 (125)
32.8
1576 (354)
1.57 2198-H040-ERSx
LDAT-S073010-EDx
…
LDAT-S073070-EDx
1.2 3.0 10.9 0.41 2198-H015-ERSx
LDAT-S074010-DDx
…
LDAT-S074070-DDx
3.5 11.9
730 (164)
43.5
2088 (469)
2.08 2198-H040-ERSx
LDAT-S074010-EDx
…
LDAT-S074070-EDx
1.8 6.0 21.7 0.95 2198-H025-ERSx
LDAT-S076010-DDx
…
LDAT-S076070-DDx
3.5 18.2
1122 (252)
66.4
3189 (717)
3.17 2198-H070-ERSx
LDAT-S076010-EDx
…
LDAT-S076070-EDx
1.8 9.1 33.2 1.45 2198-H040-ERSx
Linear Thruster
Cat. No.
Velocity, max
230V AC
m/s
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Force
N (lb)
System Peak
Stall Current
A 0-pk
System Peak
Stall Force
N (lb)
Rated Output
230V AC
kW
Kinetix 5500 Drives
(240V AC input)
LDAT-S102010-DDx
…
LDAT-S102090-DDx
2.6 5.7
456 (103)
21.0
1289 (290)
0.96 2198-H025-ERSx
LDAT-S102010-EDx
…
LDAT-S102090-EDx
1.3 2.9 10.5 0.42 2198-H015-ERSx
LDAT-S103010-DDx
…
LDAT-S103090-DDx
2.7 8.6
702 (158)
31.5 1935 (435) 1.47 2198-H040-ERSx
LDAT-S103010-EDx
…
LDAT-S103090-EDx
0.9 2.9 10.5 1388 (312) 0.30 2198-H015-ERSx
LDAT-S104010-DDx
…
LDAT-S104090-DDx
2.7 11.5
929 (209)
42.0
2578 (580)
2.07 2198-H040-ERSx
LDAT-S104010-EDx
…
LDAT-S104090-EDx
1.3 5.7 21.0 0.86 2198-H025-ERSx
LDAT-S106010-DDx
…
LDAT-S106090-DDx
2.7 17.3
1403 (315)
63.0
3871 (870)
2.94 2198-H070-ERSx
LDAT-S106010-EDx
…
LDAT-S106090-EDx
1.3 8.6 31.5 1.28 2198-H040-ERSx
