Rockwell Automation Allen-Bradley Kinetix 5700 Selection Guide

Rockwell Automation Publication KNX-SG001H-EN-P - December 2020 103
Kinetix 5500 Servo Drives
Performance Specifications with 200V-class Drive Operation and Frame 150 Linear Thrusters
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient temperature and rated line
voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Performance Specifications with 400V-class Drive Operation and Frame 30 Linear Thrusters
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient temperature and rated line
voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Linear Thruster
Cat. No.
Velocity, max
230V AC
m/s
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Force
N (lb)
System Peak
Stall Current
A 0-pk
System Peak
Stall Force
N (lb)
Rated Output
230V AC
kW
Kinetix 5500 Drives
(240V AC input)
LDAT-S152010-DDx
…
LDAT-S152090-DDx
1.8 5.3
643 (145)
19.5 1799 (404) 0.87 2198-H025-ERSx
LDAT-S152010-EDx
…
LDAT-S152090-EDx
0.9 2.7 9.8 1679 (377) 0.34 2198-H015-ERSx
LDAT-S153010-DDx
…
LDAT-S153090-DDx
1.8 8.0 978 (220) 29.1 2680 (602) 1.33 2198-H040-ERSx
LDAT-S154010-DDx
…
LDAT-S154090-DDx
1.8 10.7
1306 (294)
39.1 3597 (809) 1.78 2198-H040-ERSx
LDAT-S154010-EDx
…
LDAT-S154090-EDx
0.9 5.3 19.5 3383 (761) 0.70 2198-H025-ERSx
LDAT-S156010-DDx
…
LDAT-S156090-DDx
1.8 16.3
1997 (449)
59.4 5469 (1229) 2.71 2198-H070-ERSx
LDAT-S156010-EDx
…
LDAT-S156090-EDx
0.9 8.1 19.8 5110 (1149) 1.05 2198-H025-ERSx
Linear Thruster
Cat. No.
Velocity, max
460V AC
m/s
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Force
N (lb)
System Peak
Stall Current
A 0-pk
System Peak
Stall Force
N (lb)
Rated Output
460V AC
kW
Kinetix 5500 Drives
(480V AC input)
LDAT-S031010-DDx 2.4
4.8 81 (18) 12.2 168 (38)
0.20
2198-H015-ERSx
LDAT-S031020-DDx 3.1 0.25
LDAT-S031030-DDx 3.5 0.29
LDAT-S031040-DDx 3.8 0.31
LDAT-S032010-DDx 3.1
7.4
126 (28)
24.3
336 (76)
0.40
2198-H025-ERSx
LDAT-S032020-DDx 4.1 0.52
LDAT-S032030-DDx 4.7 0.59
LDAT-S032040-DDx 5.0 0.63
LDAT-S032010-EDx 3.1
3.7 12.2
0.40
2198-H015-ERSx
LDAT-S032020-EDx 4.1 0.52
LDAT-S032030-EDx 4.7 0.59
LDAT-S032040-EDx 5.0 0.63
LDAT-S033010-DDx 3.5
11.1
190 (43)
36.5
504 (113)
0.67
2198-H040-ERSx
LDAT-S033020-DDx 4.7 0.88
LDAT-S033030-DDx
5.0 0.95
LDAT-S033040-DDx
LDAT-S033010-EDx 3.5
3.7 12.2
0.67
2198-H015-ERSx
LDAT-S033020-EDx 4.7 0.87
LDAT-S033030-EDx
5.0 0.91
LDAT-S033040-EDx
