Rockwell Automation Publication KNX-SG001H-EN-P - December 2020 229
Kinetix 300 and Kinetix 350 EtherNet/IP Servo Drives
Performance Specifications with Kinetix 300 (400V-class, three-phase) Drives
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient temperature, and rated line
voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Linear Motor Cat. No.
Maximum Speed
m/s (ft/s)
System Continuous
Stall Current
(1)
A 0-pk
(1) Values represent the range between no cooling (low value) and water cooling (high value).
System Continuous
Stall Force
(1)
N (lb)
System Peak
Stall Current
A 0-pk
System Peak
Stall Force
N (lb)
Linear Motor
Rated Output
kW
Kinetix 300
400V-class
Three-phase Drives
LDC-C030100-DHT
10.0 (32.8)
4.1…6.1 74…111 (17…25) 12.1 188 (42) 0.37…0.55 2097-V34PR5
LDC-C030200-DHT 8.1…12.2
148…222 (33…50)
24.3
375 (84) 0.74…1.11
2097-V34PR6
LDC-C030200-EHT 4.1…6.1 12.1 2097-V34PR5
LDC-C050100-DHT
10.0 (32.8)
3.9…5.9 119…179 (27…40) 11.7 302 (68) 0.59…0.89 2097-V34PR5
LDC-C050200-DHT 7.9…11.8
240…359 (54…81)
23.3
600 (135) 1.20…1.79
2097-V34PR6
LDC-C050200-EHT 3.9…5.9 11.6 2097-V34PR5
LDC-C050300-DHT 11.8…17.7
363…544 (82…122)
35.9
941 (212) 1.81…2.72
2097-V34PR6
LDC-C050300-EHT 3.9…5.9 12.0 2097-V34PR5
LDC-C075200-DHT
10.0 (32.8)
7.7…11.5
348…523 (78…117)
22.9
882 (198) 1.74…2.61
2097-V34PR6
LDC-C075200-EHT 3.8…5.7 11.5 2097-V34PR5
LDC-C075300-EHT 3.8…5.7 523…784 (117…176) 11.9 1368 (308) 2.61…3.92 2097-V34PR5
LDC-C075400-EHT 7.7…11.5 697…1045 (157…235) 23.7 1824 (410) 3.48…5.22 2097-V34PR6
LDC-C100300-EHT
10.0 (32.8)
3.7…5.6 674…1012 (152…227) 11.4 1767 (397) 3.37…5.06 2097-V34PR5
LDC-C100400-EHT 7.4…11.1 899…1349 (202…303) 22.8 2356 (530) 4.49…6.74 2097-V34PR6
LDC-C150400-EHT
10.0 (32.8)
7.0…10.6 1281…1922 (288…432) 22.6 3498 (786) 6.40…9.61 2097-V34PR6
