Rockwell Automation Publication KNX-SG001H-EN-P - December 2020 35
Product Features Comparison
Kinetix TLP Motor Power/brake, Feedback, and Brake Cables
Cable Features Kinetix TLP Motor Power/Brake, Feedback, and Brake Cables
Catalog numbers
• 2090-CTPx-MxDF-xxAxx standard, non-flex power/brake cables
• 2090-CTPx-MxDF-xxFxx continuous-flex power/brake cables
• 2090-CTFB-MxDD-CFAxx standard, non-flex feedback cables
• 2090-CTFB-MxDD-CFFxx continuous-flex feedback cables
• 2090-CTBK-MBDF-20Axx standard, non-flex brake cables
• 2090-CTBK-MBDF-20Fxx continuous-flex brake cables
• 2090-CTPx-MxET-xxFxx continuous-flex extension power/brake cables
• 2090-CTFB-MxET-xxFxx continuous-flex extension feedback cables
• 2090-CTBK-MxET-xxFxx continuous-flex extension brake cables
Features
• Designed in accordance with NFPA-79
• Low capacitance design to maximize system power density
• 2090-CTxxMAxx-xxxxx cables with molded connectors for TLP-A046…TLP-A100 motors
• 2090-CTxxMC/MD/MExx-xxxxx cables with military connectors for TLP-A115…TLP-A235 motors
Agency compliance
• UL Recognized: 18, 16, 12, 8, 6, and 4 AWG bulk power cable
– UL AWM, 600V, 105 °C construction
– cUR AWM I/II A, 600V, 105 °C construction
• UL Recognized: Bulk feedback cable
– UL AWM, 300V, 80 °C construction for up to 20 m (65.6 ft) cable length
– UL AWM, 30V, 80 °C construction for 30 m (98.4 ft) and 50 m (164 ft) cable length
• UL Recognized: Bulk brake cable
– UL AWM, 300V, 105 °C construction
Materials
PVC cable jacket with durable mechanical and chemical properties
85% braid coverage for EMC performance
Rated flex-cycles (linear flexing applications) Continuous-flex cables and continuous-flex extension cables options
Bend radius specifications
• Static bend radius - 8x OD
• Continuous bend radius - 12x OD
General specifications
105 °C (221 °F) rated temperature
VW-1 flame test rated
Better EMC/EMI performance
Compatible rotary motors Kinetix TLP servo motors
Compatible linear actuators –
Compatible linear motors –
Compatible servo drives
•Kinetix 5100
•Kinetix 5300
