36 Rockwell Automation Publication KNX-SG001H-EN-P - December 2020
Product Features Comparison
Motor Power/brake and Feedback Cables
Cable Features Motor Power/Brake and Feedback Cables
Catalog numbers
• 2090-CPxM7DF-xxAAxx standard, non-flex power/brake cables
• 2090-CPxM7DF-xxAFxx continuous-flex power/brake cables
• 2090-CFBM7Dx-CEAAxx standard, non-flex feedback cables
• 2090-CFBM7Dx-CxAFxx continuous-flex feedback cables
• 2090-CPBM7E7-xxAFxx continuous-flex extension power/brake cables
• 2090-CFBM7E7-CxAFxx continuous-flex extension feedback cables
Features
• Designed in accordance with NFPA-79
• SpeedTec connection system
• DESINA compliant jacket (orange) coloring for easy identification and separation of cables in a machine
Agency compliance
• UL Listed bulk cable with 600V insulation rating for use in cable trays and exposed run applications
– Type TC-ER: Power-only and power-with-brake cables
– Type PLTC-ER: Feedback cable optimized for high-resolution feedback
• CSA AWM, I/II A/B, 600V, 90 °C construction
Materials
Vinyl TPE blend/PVC cable jacket with superior mechanical and chemical properties
100% braid coverage for best EMC performance
Rated flex-cycles
(linear flexing applications)
8, 10, 14, and 16 AWG continuous-flex cables and continuous-flex extension cables are suitable for 20 million flex-cycles
Bend radius specifications
•Static bend radius - 7x OD
• Continuous bend radius - 12x OD
General specifications
90 °C (194 °F) rated temperature
FT1 flame test rated, VW-1
Best EMC/EMI performance
Compatible rotary motors
• Kinetix VPC-Bxxxxx-S/Y/M
• Kinetix MPL, MPM, MPF, and MPS servo motors
• Kinetix HPK and RDB servo motors
Compatible linear actuators
• Kinetix MPAS/MPMA linear actuators
• Kinetix MPAR and MPAI electric cylinders
• LDAT-Series linear thrusters
Compatible linear motors
• LDC-Series iron-core linear motors
• LDL-Series ironless linear motors
Compatible servo drives
• Kinetix 5700
• Kinetix 5500
• Kinetix 5300
• Kinetix 5100
• Kinetix 6200/6500
• Kinetix 6000
• Kinetix 300/350
