Figure 3-31: Tandem Array Glide Puck Payload vs. Velocity
0
0.5
1.0
1.5
2.0
2.5
3.0
0 0.5 1 1.5 2 2.5
Payload (kg)
Velocity (m/s)
Dual Array (Tandem) Glide Puck Max Velocity
