Curve Track Configuration
Figure 3-65: Curve Track Configuration
• Node types at the beginning of a path: Simple, Relay, Terminus, Gateway.
• Node types at the end of a path: Relay, Terminus, Gateway.
Top View
RailsMM LITE Straight Motor
Motor Gap
MM LITE Curve Motor
