Specifications and Site Requirements
Mechanical Specifications
MagneMover LITE User Manual 197
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
Figure 4-49: Precision Rail Curve, 180°, No Joint, Spine Plate, Mechanical Drawing
0
0
17.37
41.37
2X 68.35
78.00
9.58
76.40
2X 95.00
100.42
110.30
128.5°
141.5°
R169.88
114.2°
[0.25]
6.35
All Dimensions in Millimeters
700-1622-06
