Maintenance
Repair
MagneMover LITE User Manual 427
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
6. Insert the fuse module into the PEM make sure that it is oriented correctly.
7. Close the power entry module and make sure that the cover snaps into place.
8. Return the power supply to normal operation.
DC Fuses
1. Turn off power to the MM LITE Power Supply and unplug the power cable.
2. Remove the fuse by turning the fuse holder (shown in Figure 7-32) counter-clockwise.
3. Remove the old fuse and install a new fuse.
4. Insert the fuse holder and turn the fuse holder clockwise until fully seated.
5. Return the power supply to normal operation.
NOTICE Never force the Fuse Module when inserting. Make
sure that it is not at an angle before inserting and
slides straight in.
Fuse Type Fuse Location
250V AC, 10 A ceramic slow blow fuses Single fuse per fuse holder.
