Maintenance
Repair
MagneMover LITE User Manual 433
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
Install/Replace the Lubricators on Precision Rail Vehicles
To help extend bearing and rail life, attach lubricators with felt applicators to the underside of
each precision rail vehicle. Each lubricator (see Figure 7-40) consists of an impact resistant
plastic housing, and a spring-loaded, oil impregnated felt wiper that is designed to apply a
constant film of oil to the working surfaces of the rail without imposing undue friction.
NOTE: The lubricators only lubricate the running surfaces of the rails, to lubricate the entire
rail see Manually Lubricate the Precision Rails on page 362.
The frequency of lubrication depends on the distance traveled, duty, and environ-
mental factors. Replenish lubricant as necessary using a 68 viscosity EP mineral oil
(see Refill the Lubricator on Precision Rail Vehicles on page 363).
MAGNETIC FIELD HAZARD: Strong magnets in use.
To avoid severe injury, people with pacemakers and other
medical electronic implants must stay away from the magnet
array on the vehicles (pucks).
PINCH/CRUSH HAZARD: Strong magnets in use.
To avoid injury from strong magnetic attractive forces:
• Handle only one vehicle (puck) or magnet array at a time.
• Do not place any body parts (for example, fingers)
between a magnet array and any ferrous material or
another magnet array.
• Vehicles (pucks) and magnet arrays not being used must
be secured individually in isolated packaging.
NOTICE Strong magnets in use.
To avoid damage to watches, instruments, electronics, and
magnetic media, keep metal tools, metal objects, magnetic
media (for example, memory disks/chips, credit cards, and
tapes) and electronics away from the magnet arrays.
