Specifications and Site Requirements
Mechanical Specifications
188 MagneMotion
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
MM LITE Power Supply
Figure 4-40: MM LITE Power Supply Mechanical Drawing
NOTE: See MM LITE Power Supply on page 217 for electrical specifications.
All vents must be clear for unobstructed airflow.
Ingress Protection Rating: IP30.
Exposed Materials
The power supply provides openings for airflow and must not be located where harsh condi-
tions exist.
All Dimensions in Millimeters [Inches]Weight: 2.4 kg [5.3 lb]
110-0001-00
