8. Make all communication, network, and power connections (see Connecting Motors
and Electronics on page 266 and Network Connections on page 302).
9. Assemble the next section of the system following Step 1 through Step 8 and connect
it to the previously installed section verifying that both sections are in the same plane
and level to each other.
10. Continue assembling and installing sections until the system is complete.
11. Install the vehicles (pucks) on the system (see Installing Magnet Arrays/Pucks on
page 276).
NOTE: Install vehicles (pucks) on captive closed loop systems before closing the
loop to eliminate the need to remove a guide rail.
12. Install cable chase covers once all wiring is complete and has been tested (see Install-
ing Cable Chase Covers on page 278).
13. Install the user-supplied electrical power and communication connections (see Facili-
ties Connections on page 302).
14. Create the Node Controller Configuration File (see Software on page 307).
15. Power up the system and check all operating features, safety features, and connections
(see System Check-out on page 309) and install software (see System Power-up on
page 310).
Installation Overview – MagneMotion Precision Rails
The following sequence provides an overview of the installation of the precision rail option on
a MagneMover LITE transport system using railless motors.
1. Assemble a complete section of the system stand, including the stand and beam (see
Assembling Beams on page 247 and Installing System Legs on page 248).
2. Adjust the feet on the stand section to make sure that it is flat and level (see Leveling
the MagneMover LITE on page 251).
3. Secure the stand section to the floor or other equipment as required (see Securing the
Transport System on page 252).
NOTICE Make sure that the stand system where the MagneMover
LITE motors are mounted is properly grounded to safety
ground (earth).
