Design Guidelines
Transport System Options
MagneMover LITE User Manual 133
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
Use a Lubrication Pump System
Install a lubrication pump system such as catalog number C920600 as shown in Figure 3-59.
See Install the Optional Precision Rail Lubrication Pump System on page 293.
Figure 3-59: Precision Rail System with Lubrication Pump System
Lubrication Pump
Lubrication
Lubrication Port
(2X One Each Side)
Distribution Tubing
To Next Page
