Rockwell Automation MagneMotion MagneMover LITE User Manual

Specifications and Site Requirements
Communication
232 MagneMotion
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
Figure 4-68: RS-422 Cables
Motor to Motor
An RS-422 daisy chain cable is used to connect the downstream end of one motor to the
upstream end of the next motor in the path. This cable is a standard pin-to-pin straight through
cable with a 4-pin M8 socket on one end and a 4-pin M8 socket on the other end. One M8
socket plugs into the downstream communication port on the motor and the other M8 socket
plugs into the upstream communication port on the next motor.
Table 4-41: RS-422 Cable Pinouts
M8 Nano-Mizer
®
,
4-Pin, Socket
DE-9, Plug DE-9, Socket
M8 Nano-Mizer,
4-Pin, Socket
End “A” End “B”
RxD+ 1 TxD+ 373
RxD- 2 TxD- 824
TxD+ 3 RxD+ 731
TxD- 4 RxD- 282
DE-9
DE-9
Nano-Mizer
End “A”
End “B”
(Motor)
(Node Controller)
50 m Max
Socket
Socket
Plug
Nano-Mizer
Socket
Nano-Mizer
Socket
Nano-Mizer
Socket
110-0002-XX
110-0003-XX
110-0090-XX
1
2
3
4
23
7
8
7
8
2
3
1
2
3
4
