Rockwell Automation MagneMotion MagneMover LITE User Manual

Installation
Facilities Connections
MagneMover LITE User Manual 303
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
1. Connect a Cat 5 network cable for transport system network communication from the
host controller to the Uplink connector on the network switch as shown in Figure 5-46.
NOTE: When using multiple network switches to connect all node controllers, use
one switch as the primary network switch and connect all other network
switches to it as shown in Figure 5-46.
When using multiple MagneMotion PoE network switches, connect the
Uplink from each switch to the primary network switch as shown in
Figure 5-46, do not daisy chain the PoE network switches.
When using the optional SYNC IT controllers, use a switch that is dedicated
to those controllers connected directly to the EtherNet/IP
™
port on the con-
troller dedicated to synchronization as shown in Figure 5-46.
2. Connect a Cat 5 cable for network communication from the switch to each node con-
troller, the Node Controller Hardware User Manual, MMI-UM013, for the connection
locations.
Electrical Connections
Electrical power is connected to the MM LITE transport system for operation of the motors
and other subsystems. An AC electrical connection is provided on those components that
require facility power. See Electrical Specifications on page 206 for electrical requirements.
Make sure that all electrical connections are for the appropriate voltage and power rating.
1. Connect power to each NC-S:
NOTICE The Ethernet cable that connects a PoE network
switch to the host controller or other network
switches must connect to the Uplink port. Connecting
to other ports can damage the network switches or
other devices that are connected to the network
switches.
NOTICE Do not turn on facility power until all installation procedures
have been completed.
NOTICE The NC-S node controller does not support Power
over Ethernet (PoE). Never connect these node con-
trollers to a powered Ethernet network as damage to
internal components can result.
