Installation
Facilities Connections
304 MagneMotion
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
• Connect the AC power cable from either the optional remote power supply or a
user-supplied power supply to the power distribution from the main power dis-
connect for the facility. Then, connect the DC power cable to the power con-
nector on each NC-S node controller.
• Make sure that the NC-S node controllers are grounded through the DC power
connection.
2. Connect power to each NC-E:
• Connect the AC power cable from the user-supplied power supply to the power
distribution from the main power disconnect. Then, connect the DC power
cable to the power connector on each NC-E node controller.
• Make sure that the NC-E node controllers are grounded through the DC power
connection.
3. Connect power to each NC-12:
• Connect the AC power cable from either the optional remote power supply or a
user-supplied power supply to the power distribution from the main power dis-
connect for the facility. Then, connect the DC power cable to the power con-
nector on each NC-12 node controller.
• Make sure that the Ground stud on all NC-12 node controllers is connected to
GND (PE).
4. Connect power to each NC LITE:
• When supplying Power over Ethernet to the NC LITE, make sure that the
Ethernet connection goes to a +18V DC PoE enabled network switch. Plug the
network switch power supply into the power distribution from the main power
disconnect for the facility. Then, connect the cable from the switch power sup-
ply to the switch.
NOTICE The NC-E node controller does not support Power
over Ethernet (PoE). Never connect these node con-
trollers to a powered Ethernet network as damage to
internal components can result.
NOTICE The NC-12 node controller does not support Power
over Ethernet (PoE). Never connect these node con-
trollers to a powered Ethernet network as damage to
internal components can result.
