Specifications and Site Requirements
Mechanical Specifications
MagneMover LITE User Manual 203
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
Adjustable Motor Mount Bracket
Figure 4-53: Adjustable Motor Mount Bracket Mechanical Drawing
Exposed Materials
6063-T5 AL, Anodized per MIL-A-8625F, Type II, Class 2.
304 Stainless Steel.
18-8 Stainless Steel.
Nylon.
All Dimensions in Millimeters [Inches]
C
L
[1.850]
46.98
9.00[0.354] THRU
[0.625]
15.88
[3.150]
80.0
[3.03]
77.0
[0.080]
2.03
2X 90°±1°
[1.56]
39.8
[1.250]
31.8
6.50 THRU
[0.256]
[0.625]
15.88
INSERT, TANGED, HLCL,
SLF-LKG, Ø5mm [Ø0.2in] X 5.00mm [0.200in] L
700-1427-01
