Design Guidelines
Transport System Design
MagneMover LITE User Manual 89
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
Figure 3-9: System Wiring Block Diagram, Ethernet Motor Communication
DOWNSTREAMUPSTREAM
MAGNEMOVER LITE MOTOR, 1M
MAGNEMOVER LITE SWITCH, LEFT
DOWNSTREAMUPSTREAM
DC POWER BUS
110-0016-XX
DC POWER BUS
110-0015-XX
100 - 240 VAC
50 - 60 Hz
8.5 A
ETHERNET
SWITCH
USER COMPONENTS
MAGNEMOTION COMPONENTS
HOST CONTROLLER
HUMAN
MACHINE
INTERFACE
UTP-CAT5
UTP-CAT5
MOTOR SYNC CABLE
110-0085-00
UTP-CAT5
UTP-CAT5
USB1
ETH1
ETH0
J1
ETH2
ETH1
ETH2
ETH1
P1
ETH2
ETH1
S1
P1
P1
S1
UTP-CAT5
TO NEXT
MOTOR IN
ETHERNET
CHAIN
UTP-CAT5
FROM
PREVIOUS
MOTOR IN
ETHERNET
CHAIN
DC POWER BUS END CAP
110-0107-00
+36 VDC
ML POWER SUPPLY
110-0001-00
36 VDC J1
AC POWER J3
36 VDC J2
DC ENABLE J4
DC ENABLE JUMPER PLUG
700-1288-00
DC POWER T-SPLITTER
110-0014-00
(TYPICAL TO EACH MOTOR)
SP1
SP2
SP3
SYNC IT
700-1566-00
NC-E
MMI-NC-ENET-01
+6 - 36 VDC
NETWORK
CONSOLE PWR
DIGITAL I/O
OUT
0-3
IN
0-3
