Rockwell Automation MagneMotion MagneMover LITE User Manual

Installation
Transport System Installation
MagneMover LITE User Manual 243
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
10. Create the Node Controller Configuration File (see Software on page 307).
11. Power up the system and check all operating features, safety features, and connections
(see System Check-out on page 309) and install the software (see System Power-up on
page 310).
Installation Overview – MagneMotion Supplied Mounting
The following sequence provides an overview of the installation of the MagneMover LITE
transport system using the MM LITE
™
transport system components, including stand, beam,
and motor mounts.
1. Assemble a complete section of the system stand, including the stand and beam (see
Assembling Beams on page 247 and Installing System Legs on page 248).
2. Adjust the feet on the stand section to make sure that it is flat and level (see Leveling
the MagneMover LITE on page 251).
3. Secure the stand section to the floor or other equipment as required (see Securing the
Transport System on page 252).
4. Attach cable chase cover brackets to curve and switch motor mounts (see Installing
Cable Chase Cover Brackets on page 254).
5. Attach the motor mounts to all motors and switches (see Installing Motor Mounts on
Motors and Switches on page 255).
6. Install the motors and switches, make sure that the motors and guide rails are collinear
to each other and the tops of all motors are coplanar to each other and tighten the
V-braces (see Mounting Motors and Switches on page 256, Align and Secure Motors
and Switches on page 258, and Verify Motor and Switch Installation on page 262).
NOTE: If railless motors are being used, make sure that the motor bodies are collin-
ear to each other.
If motors are installed in a wash-down environment, it must not exceed IP65.
Make sure that there is sufficient space around the motor mounting surface
for all connectors and for the bend radius of all cables.
7. Install the power supplies, node controllers, network switches, and cables (see Install-
ing Electronics on page 263).
NOTICE Make sure that the stand system where the MagneMover
LITE motors are mounted is properly grounded to safety
ground (earth).
