Transport System Limits
466 MagneMotion
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
Transport System Limits
Table A-1: MagneMotion Transport System Limits
Path Node Controller System (HLC)
Motors
20/RS-422
30/Ethernet
–
†
3,840
Node Controllers ––96
Nodes 2–
†
† When using RS-422 communication with the motors, limited by the number of RS-422 connections on the
node controller (NC LITE up to 4 connections, NC-12 up to 12 connections, NC-S up to 8 connections).
When using Ethernet communication with the motors, limited by the node controller configuration and pro-
cessor loading (NC LITE up to 5 nodes, NC-12 up to 16 nodes, NC-E up to 36 nodes, NC-S up to 16 nodes),
see the Node Controller Hardware User Manual, MMI-UM013.
320
Paths ––
†
160
Stations – – 2048
Vehicles
50/RS-422
*
300/Ethernet
* When using RS-422 communication with the motors, 50 vehicles maximum per path when all vehicles on the
path are commanded forward (downstream).
45 vehicles maximum per path when all vehicles on the path are commanded backwards (upstream).
384 5,120
‡
‡ 6,000 vehicles maximum when using HLC Control Groups.
Table A-2: MagneMotion Transport System Motion Limits
*
* The limits that are shown are at the typical payloads (contact your Motion Solution Consultant or TechCon-
nect
℠
(rockwellautomation.custhelp.com) for payload guidance). Use of a smaller payload may permit higher
limits. Use of a larger payload may lower the limits.
Acceleration Velocity Thrust
MagneMover
®
LITE
†
† The limits that are shown are for standard MagneMover LITE glide pucks. Using other pucks, or custom vehi-
cles, may permit different limits.
2.0 m/s
2
[0.2 g] 2.0 m/s [4.5 mph] 10.0 N/cycle
‡
‡ Thrust at 25% duty cycle, nominal vehicle gap is 1 mm for G3 and 1.5 mm for G4.2 magnet arrays.
QuickStick
®
100 9.8 m/s
2
[1.0 g] 2.5 m/s [5.6 mph] 16.3 N/cycle
§
§ Thrust at 4.0 A stator current with a nominal vehicle gap of 3 mm with a standard magnet array.
QuickStick
®
HT with QSMC 60.0 m/s
2
[6.1 g] 3.5 m/s [7.8 mph] 182.0 N/cycle
**
** Thrust at 10.9 A stator current with a nominal vehicle gap of 12 mm with a high flux magnet array.
QuickStick
®
HT with QSHT 5700 Inverter 60.0 m/s
2
[6.1 g] 5.0 m/s [11.2 mph] 182.0 N/cycle
**
