Introduction
MagneMover LITE Overview
36 MagneMotion
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
MagneMover LITE Overview
The MagneMover LITE (MM LITE) is an intelligent transport system that provides fast, pre-
cise motion, and positioning and tracking of small loads being transported in a transport sys-
tem. The MM LITE transport system is a configuration of linear synchronous motors and
related control electronics that move independently commanded material carriers (vehi-
cles/pucks). Each vehicle is independently moved in a controlled manner at various accelera-
tion/deceleration and velocity profiles while carrying a wide range of payloads with high
precision. The MM LITE transport system consists of the following components:
MagneMover LITE motors.
Preconfigured vehicles (pucks) or user-designed vehicles with MM LITE magnet
arrays.
Node controllers.
Power supplies.
Configuration file defining paths and nodes.
User-supplied host controller.
Optional user-designed and supplied guideway and track system.
MagneMover LITE transport systems use proven linear synchronous motor (LSM) and con-
trol technology from MagneMotion
®
. These systems offer an excellent alternative to conven-
tional belt and chain conveyors for OEM/in-machine applications and for demanding product
conveyance requirements.
MM LITE motors provide repeatable positioning with no hard stops required, bidirec-
tional travel, smooth motion, and continuous vehicle (puck) tracking and reporting.
Vehicle positioning and guidance are built into the motor with internal control
electronics.
Servo repeatability at any position: ± 0.5 mm [0.02 in] (straight motors only,
using MagneMover LITE pucks). Repeatability can vary based on the PID set-
tings that are used and track and vehicle design/structure. Repeatability is not
applicable over the gaps between motors.
Servo repeatability at process stations: ± 0.1 mm [0.004 in] (straight motors
only). Excludes the gap between motors. Calibrated vehicles (pucks) are
required. May require physical attachment of the motor to the process station.
Vehicles (pucks) are controlled individually allowing the host controller to pri-
oritize the routing of individual vehicles over different paths.
Motion is provided by small preconfigured vehicles (pucks) or user-designed vehicles
with magnet arrays that are attached to the surface closest to the motor.
Up to nine 62 mm vehicles (pucks) in motion
*
per meter.
* Maximum number of vehicles (pucks) per meter is determined using the standard single array puck on a straight
motor. Using a dual array vehicle or a curved motor decreases the number of vehicles that fit per meter.
