Fernsteuerbefehle
R&S
®
RTB2000
300Bedienhandbuch 1333.1611.03 ─ 05
Parameter:
<ConditionString> ""TRUE"" | ""FALSE""
String parameter
*RST: ""TRUE""
15.5.5.2 Zeitbegrenzung
TRIGger:A:PATTern:MODE............................................................................................. 300
TRIGger:A:PATTern:WIDTh:RANGe.................................................................................300
TRIGger:A:PATTern:WIDTh[:WIDTh]................................................................................ 301
TRIGger:A:PATTern:WIDTh:DELTa.................................................................................. 301
TRIGger:A:PATTern:MODE <PatternMode>
Disables the time limitation or sets the time comparison mode.
Parameter:
<PatternMode> OFF | TIMeout | WIDTh
OFF
Disables the time limitation.
TIMeout
Defines how long at least the result of the state pattern condition
must be true or false.
WIDTh
Defines a time range for keeping up the true result of the pattern
condition. The range is defined using TRIGger:A:PATTern:
WIDTh:RANGe.
TRIGger:A:PATTern:WIDTh:RANGe <PatternRange>
Selects how the time limit for the pattern condition is defined.
The time is specified using TRIGger:A:PATTern:WIDTh[:WIDTh], the range
around is specified using TRIGger:A:PATTern:WIDTh:DELTa.
Parameter:
<PatternRange> WITHin | OUTSide | SHORter | LONGer
WITHin
Triggers if the pattern condition remains unchanged longer than
Time - Delta and shorter than Time + Delta.
OUTSide
Triggers if the pattern condition remains unchanged either shor-
ter than Time - Delta or longer than Time + Delta.
SHORter | LONGer
Triggers if the pattern condition changes before or after the spe-
cified time.
Trigger
