Fernsteuerbefehle
R&S
®
RTB2000
315Bedienhandbuch 1333.1611.03 ─ 05
To set the range ± Δt, use SEARch:TRIGger:RISetime:DELTa.
Parameter:
<Range> LONGer | SHORter | WITHin | OUTSide
LONGer
Finds rise/fall times longer than the given time.
SHORter
Finds rise/fall times shorter than the given time.
WITHin
Finds rise/fall times inside the range time ± Δt.
OUTSide
Finds rise/fall times outside the range time ± Δt.
*RST: LONG
SEARch:TRIGger:RISetime:TIME
<Time>
Sets the reference rise or fall time, the nominal value for comparisons.
Parameter:
<Time> Bereich: Depends on various settings, mainly time base and
sample rate
*RST: 400e-6
Std.-einheit: s
SEARch:TRIGger:RISetime:DELTa <DeltaTime>
Sets a range Δt to the reference rise/fall time set with SEARch:TRIGger:RISetime:
TIME, if SEARch:TRIGger:RISetime:RANGe is set to Within or Outside. The
instrument finds rise/fall times inside or outside the range time ± Δt.
Parameter:
<DeltaTime> Bereich: Depends on various settings, mainly time base and
sample rate
*RST: 100e-6
Std.-einheit: s
15.6.4.6 Konfiguration Runt-Suche
SEARch:TRIGger:RUNT:POLarity....................................................................................315
SEARch:TRIGger:LEVel:RUNT:LOWer.............................................................................316
SEARch:TRIGger:LEVel:RUNT:UPPer............................................................................. 316
SEARch:TRIGger:RUNT:RANGe..................................................................................... 316
SEARch:TRIGger:RUNT:WIDTh...................................................................................... 316
SEARch:TRIGger:RUNT:DELTa.......................................................................................317
SEARch:TRIGger:RUNT:POLarity <Polarity>
Indicates the polarity of a the runt to be searched for.
Messkurvenanalyse
