Fernsteuerbefehle
R&S
®
RTB2000
477Bedienhandbuch 1333.1611.03 ─ 05
●
LOGic<p>:DATA:XORigin? auf Seite 385
●
LOGic<p>:DATA:YINCrement? auf Seite 386
●
LOGic<p>:DATA:YORigin? auf Seite 386
●
LOGic<p>:DATA:YRESolution? auf Seite 387
LOGic<p>:DATA?...........................................................................................................477
DIGital<m>:DATA?.........................................................................................................477
LOGic<p>:DATA:HEADer?..............................................................................................477
DIGital<m>:DATA:HEADer?............................................................................................ 477
LOGic<p>:DATA:POINts................................................................................................. 478
DIGital<m>:DATA:POINts............................................................................................... 478
LOGic<p>:DATA?
DIGital<m>:DATA?
Returns the data of the specified logic channel/pod for transmission from the instru-
ment to the controlling computer. The waveforms data can be used in MATLAB, for
example.
To set the export format, use FORMat[:DATA].
To set the range of samples to be returned, use DIGital<m>:DATA:POINts.
Suffix:
<m>
.
0..15
Selects the logic channel
<p> 1..2
Selects the logic pod
Parameter:
<WaveformData> List of values according to the format settings.
Beispiel:
FORM ASC,0
DIG1:DATA?
1,1,1,1,1,1,0,0,0,0,0,0,...
Verwendung: Nur Abfrage
LOGic<p>:DATA:HEADer?
DIGital<m>:DATA:HEADer?
Returns information on the waveform of the specified logic channel/pod.
Tabelle 15-6: Header data
Position Meaning Example
1 XStart in s -9.477E-008 = - 94,77 ns
2 XStop in s 9.477E-008 = 94,77 ns
3 Record length of the waveform in Samples 200000
4 Number of values per sample interval, usually 1. 1
Mixed-Signal-Option (Option R&S RTB-B1)
