Suffix:
<b>
.
1..2
Selects the parallel bus.
<m> Sets the bit number.
Parameter:
<DataSource> D0..D15
Beispiel:
BUS:PARallel:Width 4
BUS:PARallel:DATA0:SOURce D8
BUS:PARallel:DATA1:SOURce D9
BUS:PARallel:DATA2:SOURce D10
BUS:PARallel:DATA3:SOURce D11
15.12.2.2
Parallel getakteter Bus - Konfiguration
BUS<b>:CPARallel:CLOCk:SOURce............................................................................... 480
BUS<b>:CPARallel:CLOCK:SLOPe................................................................................. 480
BUS<b>:CPARallel:CS:ENABle.......................................................................................480
BUS<b>:CPARallel:CS:SOURce......................................................................................481
BUS<b>:CPARallel:CS:POLarity......................................................................................481
BUS<b>:CPARallel:CLOCk:SOURce <ClockSource>
Selects the logic channel that is used as clock line.
Suffix:
<b>
.
1..2
Selects the parallel bus.
Parameter:
<ClockSource> D0..D15
*RST: D0
BUS<b>:CPARallel:CLOCK:SLOPe <ClockSlope>
Selects if the data is sampled on the rising or falling slope of the clock, or on both
edges (EITHer). The clock slope marks the begin of a new bit.
Suffix:
<b>
.
1..2
Selects the parallel bus.
Parameter:
<ClockSlope> POSitive | NEGative | EITHer
BUS<b>:CPARallel:CS:ENABle <ChipSelectEnable>
Enables and disables the chip select line.
Mixed-Signal-Option (Option R&S
RTB-B1)
