Rotax 914 F - 7) Throttle Cable and Linkage; 8) Checking of Starting Carburetor (Choke)

Reference Modification no.
- 0 -
Page
104
Date
1997 02 01
Main
914 F
01477
12.3.15.7) Throttle cable and linkage
See Pic. 52.
Adjust Bowden cable to a clearance of 1 mm (.04 in). Inspect and lubricate
actuation linkage and joints with motor oil.
▲ WARNING: With carburetor levers not connected, the carburetor is fully
open. Never start the engine without carburetor Bowden
cable connected, as the home position of the CD-carburetor
is with throttle fully open.
Pic. 52
~1 mm
12.3.15.8) Checking of starting carburetor (choke)
Check Bowden cable and lever for easy movement. Bowden cable must
allow complete travel of lever from stop to stop.
00184
