Rotax 914 F - 11.6 Special tools and devices

Reference
Modification no.
- 0 -
Page
73
Date
1997 02 01
Main
914 F
01476
11.6) Special tools and devices
See Pic. 34.
The following tools and devices are also indictaed in the spare parts list.
Pic. Nr. Part-No. Description, application quantity
1 276 280 spark plug wrench 16 a/f .....................................................1
2 977 420 handle 8x130-10 .................................................................1
for spark plug wrench
3 240 880 threaded pin DIN 915-M8x50 ..............................................1
for crankshaft locking
4 876 510 insertion punch ...................................................................1
for oil seal (12x30x7), water pump shaft
5 877 250 insertion punch ...................................................................1
for rotary seal
6 877 270 insertion punch ...................................................................1
for oil seal 32x52x7, crankshaft, magneto side
7 877 276 insertion punch ...................................................................1
for oil seal 22x32x7, vacuum pump
8 276 332 insertion punch ...................................................................1
for pressing out needle sleeve 22x28x12 and ball bearing
15x32x8, vacuum pump
9 877 650 handle for various insertion punches ..................................1
10 876 518 insertion punch ...................................................................1
for oil seal 40x55x7, gearbox cover
11 877 320 insertion ring .......................................................................1
for ball bearing 35-72-17 propeller shaft, use together with
insertion punch 876 518
12 877 680 insertion punch with sleeve... ..............................................1
for oil seal 6x11x3/4,5 of rev. counter housing
13 877 410 protection piece...................................................................1
for crnakshaft, magneto side
14 - 15 877 375 extractor assy. .....................................................................1
for magneto flywheel
15 841 875 hex. screw M16x120 DIN 931 .............................................1
for extractor
16 877 360 insertion sleeve ...................................................................1
for oil seal 32x52x7, crankshaft, magneto side
17 877 295 impeller spanner .................................................................1
for water pump impeller
18 ÷ 19 877 730 float level gauge assy.,........................................................1
for check of float lever
19 240 381 hex. screw M6x12 DIN933-8.8 ............................................1
for float level gauge
20 877 710 dial gauge adapter assy., ....................................................1
21 876 950 precision dial gauge............................................................1
22 877 700 spring scale.........................................................................1
for check of valve spring force
