Rotax 914 F - 7) Calibration of the Throttle Position

ReferenceModification no.
- 3 -
Page
209
Date
1999 01 01
Main
914 F
01479
13.6.1.7) Calibration of the throttle position
See Pic. 173/1, 173/2 and 173/3.
➪ Start up of the sub program THROTTLE.
➪ Check whether the throttle (carb 2/4) can be fully opened and closed.
Verify that the Bowden cables allow the complete travel from stop to stop.
➪ Follow the directives on the display, i.e.:
➪ Close the throttle completely (carb 2/4) and confirm with ENTER.
03073
Pic. 173/3
03072
Pic. 173/2
03071
Pic. 173/1
➪ Fully open the throttle (carb 2/4) and confirm with ENTER.
➪ Calibration data will be transferred automatically and the calibration takes
place.
➪ Verification of the throttle position as per section 13.6.1.6).
