Reference
Modification no.
- 0 -
Page
260
Date
1997 02 01
Main
914 F
01480
14.11) Fitting of intake manifolds
See Pic. 012 and 106.
Place both intake manifolds showing inwards, together with O-rings 34-2 on cylinder
head and attach with Allen screws M6x25 and M6x70. Torque to 10 Nm (90 in.lb), see
also Chapter 13.4.15).
Tighten compensating tube and the hoses on both ends with hose clamps 15/9.
Attach fuel manifold with fuel lines on compensating tube, see also Chapter 13.1.5
and 13.1.8).
