Rotax 914 F User Manual

Reference Modification no.
- 0 -
Page
172
Date
1997 02 01
Main
914 F
01478
13.4.10.2) Engine, external
See Pic. 139.
Legend to wiring diagram (Pic. 139)
Position 1-20 contained in serial supply scope of engine
Position 21-25 available as accessories.
Position 30-51 not supplied by ROTAX
s WARNING: Check of parts/components which are not in the serial supply scope
of ROTAX have to be checked as per aircraft or fuselage manufac-
turer's specifications.
1 36-pole plug receptacle for TCU
2-3 plug receptacles for pressure sensor
4 plug receptacles for lamps
5 plug receptacles for servo motor
6 pressure sensor (ambient pressure)
7 pressure sensor (Airbox pressure)
8 servo motor
9 2 elektronic modules
10-11 plug receptacles for stop switch
12 internal generator
13-14 external rectifier-regulator with plug receptacles
15 electric starter
16-17 starter relais with plug receptacle
18-19 electrical fuel pumps
20 3-way solenoid valve (float chamber pressure)
21-23 external alternator with plug receptacles
24 electronic rev. counter
25 capacitor
30-31 lamps
32 switch for servo motors
33 2 short-circuit switches
34 main switch (Master Switch)
35 start switch
36 signal lamps
37 instrument (Amperemeter)
38 battery relay
39 battery
40 Bus Bar
41 capacitor
42-51 circuit breaker
