Rotax 914 F User Manual

Reference
Modification no.
- 0 -
Page
47
Date
1997 02 01
Main
914 F
01476
Y
zum hydr.Verstellregler
(optional)
to hydr. governor
Ölzulauf
oil inlet
zum Öltank
to oil tank
E
U
Q
O
I
T
R
r
y
u
P
{
}
q
W
O
w
e
W
t
0-10
bar
Legend to Pic. 20:
R valve housing
T pressure spring
Y ball 5,5 mm dia.
U banjo bolt
q oil pump housing (main oil pump)
w oil pump housing (suction oil pump)
e oil pump shaft
r oil inlet
t oil pressure switch
y oil filter
u excess pressure valve
Pic. 20
00131
