Rotax 914 F - 10) Wiring Diagrams; 1) Engine, Internal

Reference Modification no.
- 0 -
Page
170
Date
1997 02 01
Main
914 F
01478
Legend to wiring diagram (Pic. 138)
1 ignition magneto generator
2 trigger coil for ignition circuit ”A”
3 trigger coil for ignition circuit ”B”
4 trigger coil for rev. counter
5 plug receptacle 2-pole
6 electronic tachometer
7 shorting switch for ignition circuit ”A” and ”B”
8 plug receptacle 1-pole
9 plug receptacle 4-pole
10 electronic module for circuit ”A”
11 electronic module for circuit ”B”
12 double ignition coil
13 engine
14 cylinder 1 - 4
15 spark plugs
16 charging coils
V consumer connection
o colour code
13.4.10)Wiring diagrams
13.4.10.1) Engine, internal
See Pic. 138.
