ReferenceModification no.
- 0 -
Page
105
Date
1997 02 01
Main
914 F
01477
12.3.16)Check of wiring
— Check all cable plugs and connections for tight fit and good contact.
— Check all shorting connections for corrosion.
— Check plug connections between pick-up cable and electronic module
and of charging and shorting cables.
— Check plug connections between electronic module and ignition coils.
— Check plug connections of generator cables with rectifier-regulator and
connections of all cables on rectifier-regulator for good contact and tight fit.
— Check shorting cables for tight fit.
— Check shielding of cable assemblies for damage, perfect ground contact
and attachment of shielding.
— Inspect all 8 ignition cables to spark plug connector for damage and tight
fit. Check resistor plug connector for tight fit on spark plug.
— Verify tight plug connections of cable assy, on Turbo Control Unit (TCU)
on 2 pressure sensors, rev-counter pick-up, throttle potentiometer, air box
temperature sensor, servo motor, isolating switch, control valve and on
the two lamps.
