Rotax 914 F - Page 74

Reference
Modification no.
- 0 -
Page
74
Date
1997 02 01
Main
914 F
01476
23 ÷ 24 877 016 circlip installation tool assy.,................................................1
for fitting of piston pin circlips
23 877 011 insertion punch ...................................................................1
for piston pin
24 877 021 locating sleeve ....................................................................1
for fitting of iston pin circlips
25 ÷ 26 877 090 piston pin extraction tool assy., ...........................................1
for fitting and removal of piston pin
26 877 155 extracting nut M6 assy.,.......................................................1
for piston pin extraction tool
27 876 978 piston ring spanner .............................................................1
for piston 79,5 mm dia.
28 ÷ 29 877 720 valve spring clamp ..............................................................1
for removal of valve springs
29 877 380 valve spring mounting device..............................................1
for removal and isntallation of valve springs
30 877 690 test lever..............................................................................1
for check of valve spring force
31 242 660 distance nut spanner M8x33 ...............................................1
fixture for vacuum pump drive sleeve
32 876 470 ring spanner 10/13 a/f .........................................................1
33 877 260 cylinder aligning tool ...........................................................1
to align cylinders
34 ÷ 35 877 230 trestle assy., ........................................................................ 1
for engine fixation
34 876 762 trestle support .....................................................................1
35 877 240 mounting plate assy., ..........................................................1
36 877 670 cutting tool...........................................................................1
for oil filter
37 877 620 oil filter wrench 80-110 ........................................................1
for oil filter removal
38 877 390 pin-face wrench A90 DIN 3116 ...........................................1
for overload clutch
39 ÷ 40 877 445 socket 41x12,5 assy., ..........................................................1
for hex. nut 41 a/f, crankshaft p.t.o. side
39 877 440 socket S 41x20 L DIN 3124 ................................................1
40 877 460 reduction socket A 20x12,5 .................................................1
3/4" to 1/2", for socket wrench 41 a/f
41 877 450 socket S 46x20 L DIN 3121 ................................................1
for hex. nut 46 a/f, crankshaft magneto side
42 877 465 reduction socket 3/4x1 ........................................................1
1" to 3/4", for socket wrench 46 a/f
43 877 660 puller assy., .........................................................................1
for gearbox
44 876 885 mounting yoke.....................................................................1
to compress dog gear
45 ÷ 48 877 615 puller assy., .........................................................................1
for prop shaft, roller bearing 25x52x15 and oil seal 30x52x7
