Rotax 914 F User Manual

ReferenceModification no.
- 3 -
Page
215
Date
1999 01 01
Main
914 F
01479
0
0,5
1
1,5
2
2,5
3
3,5
D
rosselklappenstellun
g
t
hrottle position
Widerstand [k
Ω
]
resistance
0
0,5
1
1,5
2
2,5
3
3,5
4
4,5
5
D
rosselklappenstellun
g
t
hrottle position
Widerstand [k
Ω
]
resistance
➪ check for physical damage
➪ checking for nominal resistance
Measure resistance between terminals T and U.
Nominal resistance: 3,2 ÷ 4,8 kΩ
➪ Measuring of resistance across turning range of fitted throttle.
To check the function of the throttle position potentiometer over operating
range take the following readings:
Resistance between the terminals Y and U:
Throttle closed (throttle lever pos. 0%): 3,4 ÷ 4,6 kΩ
Throttle open (throttle lever pos. 115%): 0,8 ÷ 2,0 kΩ
◆ NOTE:
Check complete operating range
as per diagram (Pic. 179) for lin-
ear resistance progress.
open
closed
00221
Resistance between the terminals T and Y:
Throttle open (throttle lever pos. 115%): 2,4 ÷ 3,2 kΩ
Throttle closed (throttle lever pos. 0%): 100 ÷ 300 Ω
◆ NOTE:
Check complete operating range
as per diagram (Pic. 180) for lin-
ear resistance progress.
open
closed
00222
■ ATTENTION: Parts physically damaged or of not correct function have to
be exchanged without delay.
Pic. 180
Pic. 179
