Scanlab RTC 5 PC Interface Board - Page 134

RTC
®
5 PC Interface Board
Rev. 1.9 e
7 Basic Functions for Scan Head and Laser Control
134
innovators for industry
49
Laser control timing diagram for YAG modes 1, 2, 3 and 5 (with active-high laser control signals)
(the standby signals aren’t synchronized with the laser-active signals and can have arbitrary phase alignments)
LASER1
(Q-Switch)
LASER2
(FirstPulseKiller)
YAG 5
LASERON
LASER1
(Q-Switch)
LASER2
(FirstPulseKiller)
LASER1
(Q-Switch)
LASER2
(FirstPulseKiller)
YAG 2
YAG 1
LASER1
(Q-Switch)
LASER2
(FirstPulseKiller)
YAG 3
"Laser active""Laser standby" "Laser standby"
Q-Switch
Period
Q-Switch
Pulse Width
FirstPulseKiller
Length
Q-Switch
Delay
Time
LaserOff
Delay
LaserOn
Delay
FirstPulseKiller
Length
Q-Switch
Period
Q-Switch
Pulse Width
FirstPulseKiller
Length
Q-Switch
Period
Q-Switch
Pulse Width
Q-Switch
Period
Q-Switch
Pulse Width
FirstPulseKiller
Length
10 ms
Vector
Output
Start of
Vector
End of
Vector
Standby
Pulse Width
Standby
Period
Standby
Pulse Width
Standby
Period
Standby
Pulse Width
Standby
Period
Standby
Pulse Width
Standby
Period
YAG modes 1-3 and 5
