Scanlab RTC 5 PC Interface Board - write_8 bit_port_list; write_da_1; write_da_1_list; write_da_2

RTC
®
5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
557
innovators for industry
Delayed Short
List Command
write_8bit_port_list
Function same as write_8bit_port (see above), but a list command
Call
write_8bit_port_list( Value )
Parameter Value 8-bit output value (DATA0…DATA7) as an unsigned 32-bit value
(only the least significant 8 bits are evaluated).
Comments • See write_8bit_port.
RTC
®
4  RTC
®
5 unchanged functionality
Ctrl Command write_da_1
Function see write_da_x
Call
write_da_1( Value )
Parameter Value 12-bit output value for the ANALOG OUT1 analog output port as an unsigned
32-bit value. Higher bits are ignored.
Value = 0 corresponds to an output value of 0 V,
Value = 2
12
–1 to an output value of 10 V.
RTC
®
4  RTC
®
5 unchanged functionality
In RTC
®
4 compatibility mode: as write_da_x
Delayed Short
List Command
write_da_1_list
Function see write_da_x_list
Call
write_da_1_list( Value )
Parameter Value 12-bit output value for the ANALOG OUT1 analog output port as an unsigned
32-bit value. Higher bits are ignored.
Value = 0 corresponds to an output value of 0 V,
Value = 2
12
–1 to an output value of 10 V.
RTC
®
4  RTC
®
5 unchanged functionality
In RTC
®
4 compatibility mode: as write_da_x
Ctrl Command write_da_2
Function see write_da_x
Call
write_da_2( Value )
Parameter Value 12-bit output value for the ANALOG OUT2 analog output port as an unsigned
32-bit value. Higher bits are ignored.
Value = 0 corresponds to an output value of 0 V,
Value = 2
12
–1 to an output value of 10 V.
RTC
®
4  RTC
®
5 unchanged functionality
In RTC
®
4 compatibility mode: as write_da_x
