RTC
®
5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
270
Control
Command
get_jump_table
Function retrieves the board’s currently stored jump delay table and copies the 1024 corresponding
unsigned 16-bit values to the supplied PC address.
Call
ErrorCode = get_jump_table( Addr )
Parameters
Addr
PC Address of a 2048-byte area of PC main memory
Return Error code as unsigned 32-bit value:
0 no error
11 driver error
Notes • Do not call this command during processing of a list.
• The data format is “1024 16-bit values“ representing the delay values for a piecewise
linear interpolation at the sampling points (=jump lengths) N · 1024 with 0 N<
1024. The values can thus also be directly generated or modified by the user.
RTC
®
4
RTC
®
5new command
Version info Available beginning with version DLL 525
Reference set_jump_table, load_jump_table_offset
Ctrl Command get_laser_pin_in
Function returns the current status of the two digital inputs at the laser connector
Call
LaserPinIn = get_laser_pin_in()
Result unsigned 32-bit value:
Bit #0 (LSB) DIGITAL IN1
Bit #1 DIGITAL IN2
Bits #2-31 reserved
Comments • Both inputs can be used as desired by the user.
RTC
®
4
RTC
®
5 new command
References set_laser_pin_out
Ctrl Command get_last_error
Function returns an error code listing any errors which occurred during execution of the most recent
command
Call
LastError = get_last_error()
Result error code as an unsigned 32-bit value
If multiple errors occurred simultaneously, then multiple bits will be set.
The meanings of bit numbers, error types and error constants is identical to those for the
command get_error.
Comments • For error handling see page 87.
•The commands get_last_error and n_get_last_error are also available without explicit
access rights to a specific RTC
®
5 board.
• The board-specific error variables
LastError
and
AccError
(see "Error Handling", page
87) are neither generated nor altered by get_last_error.
RTC
®
4
RTC
®
5 new command
References get_error, reset_error, set_verify
